Compact and Robust Design
The fan's compact design is achieved through the use of an outer rotor motor, which is built into the volute and directly connected to the impeller. This design not only saves space but also enhances the fan's durability and reliability. The fan's components are manufactured using precision stamping dies, ensuring accurate dimensions and profiles, and are assembled with rivets for a sturdy construction.
Aerodynamic Performance
The impeller of the DKT-400M is formed by riveting forward-curved blades to the wheel cover and middle plate. Each component is made with precision, ensuring good aerodynamic performance. The fan undergoes dynamic and static balance correction, which results in stable operation and low noise levels.
Aesthetic and Functional Design
The fan's appearance is enhanced by its sleek design, which is both visually appealing and functional. The volute is made using special equipment for biting and wrapping, resulting in a sturdy and durable structure with a beautiful appearance. The fan's compact structure and various sizes make it easy to install and integrate into different systems.
Versatile Applications
The DKT-400M Multi-wing Double inlet air conditioning Fan is versatile and can be used in a variety of applications. It is suitable for air conditioning units, air curtains, cooling and heating fans, and ventilation systems in industrial and mining enterprises and public buildings.
Energy Efficiency
The DKT-400M Multi-wing Double inlet air conditioning Fan is designed with energy efficiency in mind. The integration of the outer rotor motor directly with the impeller reduces energy losses associated with mechanical transmission, resulting in higher overall system efficiency. This not only helps in reducing operational costs but also contributes to a more sustainable and environmentally friendly operation, aligning with the growing demand for energy-efficient solutions in the HVAC industry.
Customization Options
Recognizing that different applications may have unique requirements, the DKT-400M fan offers a range of customization options. Customers can choose from various power ratings, voltage configurations, and insulation classes to match the specific needs of their air conditioning systems. Additionally, the availability of different frame materials, such as carbon steel and stainless steel, allows for the selection of a fan that is better suited to the environmental conditions of the installation site, whether it be a standard indoor setting or a more corrosive industrial environment.
Long-Term Value
Investing in the DKT-400M Multi-wing Double inlet air conditioning Fan offers long-term value to the end-user. The fan's durability, combined with its low maintenance requirements, means that it will provide reliable service over an extended period. The initial investment in a high-quality fan like the DKT-400M is offset by the reduced energy consumption, lower operating costs, and the peace of mind that comes with knowing that the air conditioning system is equipped with a component that is built to last.
